Slot Strap Set (A Type) (BJ156-A)
- Volume Discount
Imao Corporation hold-down clamp, slot strap set (A Type) (BJ156-A)
Japanese Only
Part Number
Configured Part Number is shown.
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | RoHS | Clamping Force (N) | Length L (mm) | Thread Diameter M | Length H (mm) |
|---|---|---|---|---|---|---|---|---|---|
MYR 196.81 | 1 Piece(s) | 9 Day(s) | 10 | 7600 | 50 | M8×1.25 | 51 | ||
MYR 197.44 | 1 Piece(s) | 9 Day(s) | 10 | 7600 | 50 | M8×1.25 | 66 | ||
MYR 203.03 | 1 Piece(s) | 9 Day(s) | 10 | 8300 | 63 | M8×1.25 | 51 | ||
MYR 203.66 | 1 Piece(s) | 9 Day(s) | 10 | 8300 | 63 | M8×1.25 | 66 | ||
MYR 222.31 | 1 Piece(s) | 9 Day(s) | 10 | 8400 | 80 | M8×1.25 | 55 | ||
MYR 222.94 | 1 Piece(s) | 9 Day(s) | 10 | 8400 | 80 | M8×1.25 | 66 | ||
MYR 223.56 | 1 Piece(s) | 9 Day(s) | 10 | 12200 | 63 | M10×1.5 | 62 | ||
MYR 230.09 | 1 Piece(s) | 9 Day(s) | 10 | 12200 | 63 | M10×1.5 | 80 | ||
MYR 243.15 | 1 Piece(s) | 9 Day(s) | 10 | 17700 | 80 | M10×1.5 | 63 | ||
MYR 249.68 | 1 Piece(s) | 9 Day(s) | 10 | 17700 | 80 | M10×1.5 | 80 | ||
MYR 252.48 | 1 Piece(s) | 9 Day(s) | 10 | 18800 | 100 | M10×1.5 | 66 | ||
MYR 259.01 | 1 Piece(s) | 9 Day(s) | 10 | 18800 | 100 | M10×1.5 | 81 | ||
MYR 257.77 | 1 Piece(s) | 9 Day(s) | 10 | 21600 | 63 | M12×1.75 | 80 | ||
MYR 259.01 | 1 Piece(s) | 9 Day(s) | 10 | 21600 | 63 | M12×1.75 | 101 | ||
MYR 271.14 | 1 Piece(s) | 9 Day(s) | 10 | 21000 | 80 | M12×1.75 | 80 | ||
MYR 272.07 | 1 Piece(s) | 9 Day(s) | 10 | 21000 | 80 | M12×1.75 | 101 | ||
MYR 303.48 | 1 Piece(s) | 9 Day(s) | 10 | 25800 | 100 | M12×1.75 | 80 | ||
MYR 304.72 | 1 Piece(s) | 9 Day(s) | 10 | 25800 | 100 | M12×1.75 | 101 | ||
MYR 330.54 | 1 Piece(s) | Available | 11 Day(s) or more | 10 | 27500 | 125 | M12×1.75 | 80 | |
MYR 331.78 | 1 Piece(s) | Available | 11 Day(s) or more | 10 | 27500 | 125 | M12×1.75 | 101 | |
MYR 358.53 | 1 Piece(s) | Available | 11 Day(s) or more | 10 | 32500 | 160 | M12×1.75 | 85 | |
MYR 359.46 | 1 Piece(s) | Available | 11 Day(s) or more | 10 | 32500 | 160 | M12×1.75 | 101 | |
MYR 333.34 | 1 Piece(s) | 9 Day(s) | 10 | 26000 | 80 | M16×2 | 81 | ||
MYR 340.80 | 1 Piece(s) | 9 Day(s) | 10 | 26000 | 80 | M16×2 | 96 | ||
MYR 373.77 | 1 Piece(s) | 9 Day(s) | 10 | 25300 | 100 | M16×2 | 84 | ||
MYR 381.54 | 1 Piece(s) | 9 Day(s) | 10 | 25300 | 100 | M16×2 | 99 | ||
MYR 397.09 | 1 Piece(s) | 9 Day(s) | 10 | 31100 | 125 | M16×2 | 87 | ||
MYR 410.46 | 1 Piece(s) | 9 Day(s) | 10 | 31100 | 125 | M16×2 | 102 | ||
MYR 432.23 | 1 Piece(s) | 9 Day(s) | 10 | 33400 | 160 | M16×2 | 87 | ||
MYR 445.92 | 1 Piece(s) | 9 Day(s) | 10 | 33400 | 160 | M16×2 | 102 |
Loading...
Basic Information
| Tightening Force (Range Selectable)(N) | 3000～ | Type | Main Body |
|---|
Specification/Dimensions
-
Clamping Force(N)
-
Length L(mm)
-
Thread Diameter M
- M8×1.25
- M10×1.5
- M12×1.75
- M16×2
-
Length H(mm)
-
type
- BJ
-
CAD
- 2D
- 3D
Days to Ship
-
- All
- 9 Day(s) or Less
- 11 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
