Stainless Steel Caster Swivel JA Type Size 200 mm
- Volume Discount
A free-swivel caster in which rust-resistant stainless steel has been used for all hardware.
Japanese Only
| Part Number |
|---|
| CRJA-200 |
| PBDJA-200 |
| PBJA-200 |
| PJA-200 |
| PNAJA-200 |
| PNDJA-200 |
| PNJA-200 |
| PNUAJA-200 |
| PNUDJA-200 |
| PNUJA-200 |
| SHJA-200 |
| SJA-200 |
| SRJA-200 |
| SUIEJA-200 |
| SUIJA-200 |
| UWAJA-200 |
| UWBDJA-200 |
| UWBJA-200 |
| UWBSDJA-200 |
| UWBSJA-200 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Load Range (daN) | Wheel specification | Wheel Characteristics | Properties | Max. Load (daN) | Tire width R (mm) | Load Category | Shaft Bearing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
MYR 762.53 | 1 Piece(s) | Available | 8 Day(s) or more | 220.01~320.00 | [Synthetic Rubber] Heat Resistant Rubber | Abrasion Resistance / Chemical Resistance | - | 250 | 45 | Light/Medium Load | Steel Plate with Bearing | |
MYR 811.50 | 1 Piece(s) | Available | 8 Day(s) or more | 320.01~485.00 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Cold Resistance | - | 400 | 45 | Heavy Load | Stainless Steel Bearing | |
MYR 717.90 | 1 Piece(s) | Available | 8 Day(s) or more | 320.01~485.00 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Cold Resistance | - | 400 | 45 | Heavy Load | Steel Plate with Bearing | |
MYR 690.39 | 1 Piece(s) | Available | 8 Day(s) or more | 220.01~320.00 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Cold Resistance | - | 250 | 45 | Light/Medium Load | Slide Bearing | |
MYR 662.50 | 1 Piece(s) | Available | 8 Day(s) or more | 140.01~220.00 | [Synthetic Rubber] Rubber | Abrasion Resistance | - | 160 | 42 | Light/Medium Load | Slide Bearing | |
MYR 780.74 | 1 Piece(s) | Available | 8 Day(s) or more | 140.01~220.00 | [Synthetic Rubber] Rubber | Abrasion Resistance | - | 220 | 42 | Light/Medium Load | Stainless Steel Bearing | |
MYR 669.50 | 1 Piece(s) | Available | 8 Day(s) or more | 140.01~220.00 | [Synthetic Rubber] Rubber | Abrasion Resistance | - | 220 | 42 | Light/Medium Load | Steel Plate with Bearing | |
MYR 738.11 | 1 Piece(s) | Available | 8 Day(s) or more | 220.01~320.00 | [Urethane] Urethane | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | - | 250 | 42 | Light/Medium Load | Slide Bearing | |
MYR 855.67 | 1 Piece(s) | Available | 8 Day(s) or more | 320.01~485.00 | [Urethane] Urethane | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | - | 350 | 42 | Heavy Load | Stainless Steel Bearing | |
MYR 756.46 | 1 Piece(s) | Available | 8 Day(s) or more | 320.01~485.00 | [Urethane] Urethane | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | - | 350 | 42 | Heavy Load | Steel Plate with Bearing | |
MYR 734.61 | 1 Piece(s) | Available | 8 Day(s) or more | 220.01~320.00 | [Synthetic Rubber] High impact rubber | Abrasion Resistance | - | 250 | 45 | Light/Medium Load | Steel Plate with Bearing | |
MYR 668.53 | 1 Piece(s) | Available | 8 Day(s) or more | 220.01~320.00 | [Synthetic Rubber] Rubber | Abrasion Resistance | - | 250 | 45 | Light/Medium Load | Steel Plate with Bearing | |
MYR 745.86 | 1 Piece(s) | Available | 8 Day(s) or more | 140.01~220.00 | [Synthetic Rubber] Red rubber | Abrasion Resistance | - | 200 | 45 | Light/Medium Load | Steel Plate with Bearing | |
MYR 1,085.57 | 1 Piece(s) | 9 Day(s) or more | 320.01~485.00 | [Urethane] Conductive urethan | Antistatic | Static electricity prevention | 400 | 42 | Heavy Load | Steel Plate with Bearing | ||
MYR 734.31 | 1 Piece(s) | Available | 8 Day(s) or more | 320.01~485.00 | [Urethane] Urethane | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance | - | 400 | 42 | Heavy Load | Steel Plate with Bearing | |
MYR 1,303.31 | 1 Piece(s) | 20 Day(s) or more | 485.01~750.00 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Heat resistant / Cold Resistance | - | 500 | 42 | Heavy Load | Slide Bearing | ||
MYR 1,645.67 | 1 Piece(s) | 20 Day(s) or more | 485.01~750.00 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Heat resistant / Cold Resistance | - | 500 | 42 | Heavy Load | Stainless Steel Bearing | ||
MYR 1,383.92 | 1 Piece(s) | 20 Day(s) or more | 485.01~750.00 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Heat resistant / Cold Resistance | - | 500 | 42 | Heavy Load | Steel Plate with Bearing | ||
MYR 1,302.22 | 1 Piece(s) | 20 Day(s) or more | 485.01~750.00 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Heat resistant / Cold Resistance | - | 500 | 34 | Heavy Load | Stainless Steel Bearing | ||
MYR 1,109.44 | 1 Piece(s) | 20 Day(s) or more | 485.01~750.00 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance / Heat resistant / Cold Resistance | - | 500 | 34 | Heavy Load | Steel Plate with Bearing |
Loading...
Basic Information
| Mounting Height H1(mm) | 250 | Caster Type | Plate Type Universal | Size A or outer diameter A of the tire(Ø) | 200 |
|---|---|---|---|---|---|
| Stopper (Detail) | No | Fitting Material | SUS304 | Mounting Hole Pitch Transverse Direction(mm) | 112 |
| Mounting Hole Pitch Longitudinal direction(mm) | 112 | Mounting Hole Type | Round hole | Top Plate F1(mm) | 140 |
| Top Plate F2(mm) | 140 | Shaft Diameter D(Ø) | 20 | Eccentricity E(mm) | 58 |
| Metal Fitting Specifications | The wheels on earth |
Specification/Dimensions
-
Load Range(daN)
- 140.01~220.00
- 220.01~320.00
- 320.01~485.00
- 485.01~750.00
-
Wheel specification
- Synthetic Rubber
- Nylon
- Urethane
- Synthetic Rubber
-
Wheel Characteristics
- Abrasion Resistance
- Gasoline Resistance (Light Oil included)
- Oil Resistance
- Chemical Resistance
- Heat resistant
- Cold Resistance
- Antistatic
-
Properties
- Static electricity prevention
-
Max. Load(daN)
-
Tire width R(mm)
-
Shaft Bearing
- Slide Bearing
- Stainless Steel Bearing
- Steel Plate with Bearing
-
type
- JA
Days to Ship
-
- All
- 8 Day(s) or Less
- 9 Day(s) or Less
- 20 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
